LilyGo T-Beam V1.2 (SX1276)

LilyGo (Shenzhen Xinyuan Electronic Technology)

868 MHz 915 MHz SX1276 ESP32 20 dBm
DIY Modules Budget Tracker/GPS

Bewährtes GPS-Board mit SX1276-Chip. Breite Community, viele Code-Beispiele. AXP192 Power-Management, 18650-Akku-Halterung. Community-Firmware: Companion BLE/USB, Repeater, Room Server.

Hardware Specifications

MCU

ESP32

RAM

520 KB

Flash

4 MB

Display

-

Button Count

2

Has LEDs

true

Weight

50 g

Dimensions

75 x 33 x 15

LoRa Specifications

LoRa Chip

SX1276

Frequency Band

868 MHz, 915 MHz

Max. TX Power

20 dBm

Antenna Type

SMA connector

Typical Range

15 km

Connectivity

WiFi

true

Bluetooth

true

GPS

true

Power

USB Type

Micro-USB

Battery Connector

18650 Holder

Solar Support

true

Power Consumption (Idle)

55 mA

Power Consumption (TX)

130 mA
