RAK11310 WisBlock Core

RAKwireless

868 MHz 915 MHz SX1262 RP2040 22 dBm
DIY Modules Budget

WisBlock Core-Modul auf RP2040-Basis (Raspberry Pi Foundation) mit SX1262 LoRa-Transceiver. Dual-Core ARM M0+ mit 133 MHz. RP2040 hat kein integriertes WLAN/BT – BLE-Konnektivität nur via separatem WisBlock-Modul. Günstige Einstiegsoption für RP2040-Entwickler im WisBlock-Ökosystem. Drag-and-drop UF2-Flashen. MeshCore ab v1.12.0. Community-Firmware: Companion USB, Repeater, Room Server.

Hardware Specifications

MCU

RP2040

RAM

264 KB

Flash

2 MB

Display

Optional via WisBlock

Button Count

1

Has LEDs

true

Weight

5 g

Dimensions

30 x 20 x 3

LoRa Specifications

LoRa Chip

SX1262

Frequency Band

868 MHz, 915 MHz

Max. TX Power

22 dBm

Antenna Type

U.FL/IPEX (via Base Board)

Typical Range

15 km

Connectivity

WiFi

false

Bluetooth

false

GPS

false

Power

USB Type

USB-C (via Base)

Battery Connector

WisBlock Battery Connector

Solar Support

true

Power Consumption (Idle)

15 mA

Power Consumption (TX)

90 mA
